Five 10-Megapixel Digicams: Small Cameras, Big Files; Canon’s PowerShot G7, Casio’s EXILIM EX-Z1000, Olympus’ Stylus 1000, Panasonic’s Lumix DMC-LX2, Samsung’s NV10

sorcadmin's picture

Who would have thought that back when I bought my Olympus C-2100, which then boasted a 2-megapixel CCD, that one day I would be writing about cameras a fraction of its size with 10-megapixel imaging sensors? Interestingly, that camera sported a 10x optical zoom with Optical Image Stabilization (both courtesy of Canon). The cameras currently under discussion don't have 10x zooms, although the Canon PowerShot G7 comes closest at 6x optical zoom with Optical Image Stabilization. Each camera is a marvel in its own right and it took extensive testing to help me choose the pick of the litter.

The main issue with all these cameras is sensor size and consequent image quality. Are we losing anything by packing so many pixels onto a condensed sensor? Look at it this way. A can of concentrated orange juice, when reconstituted, will never have the same flavor and texture as a container of premium orange juice--even though they deliver the same quantity in the end. The same with sensor pixels. If you take the same overall number of pixels but shrink each pixel in order to fit them onto a smaller platform to deliver the same resolution as a camera with a larger sensor, when that file is "reconstituted" the logic is that something gets lost--image quality suffers.

Each of these 10-megapixel cameras is a marvel in its own right. Having said that, the Canon PowerShot G7 (rear left) outperformed all other contenders, although the Panasonic Lumix DMC-LX2 (rear right) was a close second. Of the three miniature cameras, the Samsung NV10 (middle) was the most stylish, while both the Casio EXILIM EX-Z1000 (front left) and Olympus Stylus 1000 (front right) had ease of use going for them.

The loss of image quality becomes most apparent when you expose at elevated ISO (light sensitivity) levels. Think of driving tiny, inexpensive speakers to the same volume as more robust, high-quality speakers: the sound comes out harsh and tinny from the small speakers, whereas the larger, more robust speakers deliver a sound we can enjoy for hours. With digital images, squeezing smaller pixels onto a smaller sensor translates into noisy pictures. To some degree, algorithms on-board the camera can successfully mediate this noise to deliver reasonable, even high-quality, images--up to a point.

Pushing The Limits At 10 Megapixels
Just as you can only push film so far, you can only push light sensitivity in a sensor so far before the image begins to seriously deteriorate. I put each of the cameras to the test, mounting them on a tripod, and made exposures at ISO 100 and 400, and, where available, ISO 800 and 1600. Because of the bright subject/background tonality, I increased exposure by +1 EV universally. This step benefited two cameras, but not the others in delivering a usable exposure, which is also a testament to their metering prowess, or lack thereof--or it may reflect a limitation of the camera's f/stop and shutter speed range. Either way, a poor exposure is a poor exposure.

Arguably the Canon PowerShot G7 produced the best image in Landscape Scene mode, although you have to admire the 16:9 rendition that the Panasonic Lumix DMC-LX2 delivered.
All Photos © 2007, Jack Neubart, All Rights Reserved

My tests convinced me not to exceed ISO 400 with most of these 10-megapixel cameras, although I would prefer to shoot at ISO 100 wherever possible for optimal, virtually noise-free quality. The one camera that failed to deliver satisfactory results at ISO 400 was the Casio. In fact, even at ISO 100, the EXILIM EX-Z1000 exhibited more noise than any other camera tested. The Canon fared best, delivering reasonable results even at ISO 1600.

Digital Anti-Shake Vs. Optical Image Stabilization
These cameras utilize two different Anti-Shake systems, digital and optical. Digital Anti-Shake processing means one thing: interpolated pixels. Optical Image Stabilization (OIS in Canon's PowerShot G7 and Panasonic's Lumix DMC-LX2) physically corrects for camera movement within the lens. Depending on the camera, the effective range of shutter speeds with OIS varies but it can be set to operate while the camera is held still, or alternatively, when panned, or the camera may offer continuous motion correction.

To test the effectiveness of either approach, I made handheld exposures over a range of relatively slow shutter speeds with and without this feature engaged. Shooting in Shutter-Priority mode where applicable (not available on the Olympus Stylus 1000 or the Samsung NV10), I selected a shutter speed of 1/8 sec as the critical value where Image Stabilization proved effective on all models. Clearly, my test results did not yield optimum exposure or color balance--but that wasn't what I was looking for here. As expected, OIS was the winner, with the Canon and Panasonic both proving their mettle (you have to look beyond the focusing, which at this range, proved a problem for the Panasonic). The Casio and Samsung cameras appear to suffer most from interpolated pixels, with very noisy results, while the Olympus model didn't fare much better.

Other Tests
I also wanted to see how long each camera took to make an exposure once focus was locked in, a test for what's commonly called shutter lag. The Canon averaged about 1/10 sec, with the Casio coming in just over that. The Panasonic and Samsung lagged behind at around 3/10 sec, with the Olympus taking a fraction longer. Viewing and focusing in every test was done via the LCD monitor.

Setting each camera to Snow Scene mode (where available), I photographed a snow-covered scene in New York's Central Park late in the afternoon. This mode improved color balance and exposure in the Canon PowerShot G7 image, but left the Olympus Stylus 1000 shot with a slight blue cast. Since the Casio EXILIM EX-Z1000 lacked this mode, I had fun with this camera by setting BestShot for an Illustration effect that produced a painterly quality.

Next came color balance under a fluorescent light and shady window light. In AWB (Auto White Balance) with a daylight full-spectrum fluorescent bulb (an OTT-LITE desk lamp), none of these cameras delivered clean results, although the Canon and Olympus came closest, with the Panasonic on their heels. Worst was the Casio, with the Samsung falling midway. Interestingly, only the Casio produced a neutral color balance when daylight fluorescent WB was engaged.
