Large Format Darkroom; Mix And Match For Fun And Ease

sorcadmin's picture
Photos © 2004, Frances E. Schultz, All Rights Reserved

Large format is fun: magical tonality, and detail in the print that goes on and on. Better still, it's easy. If you already have a darkroom, you probably have everything you need to make large format contact prints, and as noted below, even enlargers aren't necessarily a great problem. If you don't have a darkroom, large format is (believe it or not) one of the easiest ways to get started.

Of course you can indulge in all kinds of refinements if you want, even unto the Zone System, but you don't need to worry about these at first: even sloppy large format technique will give better results than the vast majority of 35mm or rollfilm photography. That's why it survived so long in press photography!

Church, St. Leger de Montbrun, France. Although I've shot quite a lot of 4x5", I hadn't done very much 5x7" until recently. But our 5x7" Linhof Technika V handles very much like our "baby" (rollfilm) Linhofs and I am increasingly attracted to the format. The detail in the contact prints goes on forever, and a 3x enlargement is 15x21". Other technical details: 210mm f/5.6 Rodenstock APO-Sironar-N, Cromatek orange filter in Cromatek holder, Ilford FP4 Plus at 100 in Ilford DD-X, contact printed on Ilford MG Warmtone.

The main choice is between 4x5", where you really need an enlarger, and larger formats, where contact printing is fine. Up to about a 3x enlargement--12x15" off 4x5" or 15x21" off 5x7"--you get almost contact print quality, while contact prints as small as 5x7" can have a jewel-like quality that is extremely difficult to achieve any other way. Edward Weston, remember, was a great devotee of 5x7". Really big formats, above 8x10", are much harder to handle in the dark: the film is huge and floppy and slithery, all at once.

Enlarge Or Scan
Enlargers may be less of a problem than you might expect. Many professionals today either buy in darkroom services, or are going digital. This means lots of large format darkroom equipment going cheap or even free. Many 4x5" enlargers take up little more space than a medium format enlarger, and I actually use a 5x7" enlarger: you can often find these for the same sort of money as 4x5". They are pretty big but should still fit in any but the smallest darkrooms, unlike 8x10" and bigger: one 11x14" enlarger offered free to a good home was two stories high, "buyer" collects. A well-made large format enlarger can be used for smaller formats, too. I used to print 35mm with my 5x7" MPP enlarger using a De Vere color head.

Another possibility is scanning. Even a low-resolution scanner is perfectly adequate, because the negatives are so big. A 600dpi scan allows a 2x enlargement to the standard photomechanical resolution of 300dpi, or 3x to the usual ink jet standard of 200dpi. From an 8x10" negative this is 16x20" (300dpi) or 24x30" (ink jet). Few people need bigger; even fewer own ink jet printers bigger than "super A3" (call it 11x17").

(A Left & B Right) Poppy. I've always liked this more as a negative (black on white) than as a positive (white on black) and scanning the negative offers a quick, easy way of making a negative print without making an internegative.

Scanned at 600dpi, the 5x7" negative can be enlarged to 10x14" for photomechanical reproduction (300dpi) or 15x21" for ink jet printing (200dpi)--and my ink jet printer only goes to about 14x17".

Loading And Development
The first step with large format in the darkroom is loading the film. You don't need much space for this--my loading space is 3x2 ft--but it must be bone dry and dust free. Because you are working in complete darkness (except with Ilford's Ortho Plus, where you can use a deep red safelight), you need to lay everything out the same way every time so you don't have to grope around in the dark. The film, of course, has a notch code on the top right for orientation.

Now for development. You can use trays, drums, tubes, daylight developing tanks, or a deep tank. As with film loading, you need to be meticulous regardless of the method you use.

Tray development is simple, requiring no great expenditure except a box of latex gloves: using tongs invites scratches, and using bare fingers invites dermatitis. It is the only practicable route for films above 8x10".

Fill the trays and lay them out in sequence. The timer must be easy to use in the dark. Temperature is important, too. Unlike prints, which are developed to completion, film must be developed for the right time at the right temperature. You therefore need a water bath; or a tray heater; or a warm darkroom; or a lot of developer, so it won't cool down too fast. Otherwise, developing large format film is pretty much the same as developing a black and white print, except that you are working in the dark, not by safelight (again, except for Ilford's Ortho Plus).

Unload the film on the loading bench, then put it in the developer. Some people develop multiple sheets at the same time, pulling one off the bottom, putting it on top, pulling the next one off the bottom, and so forth. I'm not brave enough for this: I'm too worried about scratching. Plenty do it successfully, though.

(C) Pitchfork Head. If it is feasible, it often looks good to print the negative "all in" with the rebate forming a frame to the image: a mask (or as here) a four-blade easel allows a broad white border outside the frame. (Linhof Technika V, 165mm f/6.8 Goerz Dagor, Ilford FP4 Plus at 100 in Ilford DD-X, contact printed on Ilford MG Cooltone, light selenium toning.)
